DW® l Blackjack Rackmount Servers

Scalable, enterprise-level servers, powered by DW Spectrum^® IPVMS.

What are Blackjack^® rackmount servers?

DW’s Blackjack^® rackmount servers powered by DW Spectrum^® are robust and user-friendly 2U to 4U servers, highly optimized to provide unlimited scalability, unmatched bandwidth savings and simplified system setup and management. The powerful hardware gives users all the tools they need to build a comprehensive, fast and reliable solution to match any application.

Choose your own Blackjack^® | View All Products| Download Brochure | Schedule a Demo

Blackjack^® Rackmountable Servers (slide to see all models):


Model		Blackjack^® P-Rack™ 1U	Blackjack^® P-Rack™ 2U	Blackjack^® P-Rack™ 2U w/RAID	Blackjack^® E-Rack™ 4U - 36 Bay	Blackjack Rack 2U - 12 Bay	Blackjack Rack 2U - 12 Bay	Blackjack Rack 2U - 18 Bay	Blackjack Rack 2U - 26 Bay
Included Licenses		4	4	4	8	8	8	8	8
Form Factor		1U rackmount	2U rackmount	2U rackmount	4U rackmount	2U rackmount	2U rackmount	2U rackmount	2U rackmount
Operating System	Windows 10	DW-BJP1UxxT	DW-BJP2UxxT	DW-BJPR2UxxT	DW-BJER4UxxT	DW-BJRR2UxxT	DW-BJRR2PxxT	DW-BJRR2XxxT	DW-BJRR2YxxT
	Linux Ubuntu	DW-BJP1UxxT-LX	DW-BJP2UxxT-LX	DW-BJPR2UxxT-LX	DW-BJER4UxxT-LX	DW-BJRR2UxxTLX	DW-BJRR2PxxTLX	DW-BJRR2XxxTLX	DW-BJRR2YxxTLX
	Windows Server	---	---	---	---	DW-BJRR2UxxTS	DW-BJRR2PxxTS	DW-BJRR2XxxTS	DW-BJRR2YxxTS
CPU		Intel^® i5^® processor	Intel^® i7^® processor	Intel^® i7^® processor	Intel^® i7^® processor	Intel^® Xeon^® processor	Dual Intel^® Xeon^® processor
Memory		16GB	16GB	16GB	16GB	16GB	32GB
Ethernet Ports		2x gigabit ethernet ports (RJ45)	2x gigabit ethernet ports (RJ45)	2x gigabit ethernet ports (RJ45)	2x gigabit ethernet ports (RJ45)	2x gigabit ethernet ports (RJ45)	2x gigabit ethernet ports (RJ45)	6x 1GB Base-T Ethernet Ports	2x 1GB Base-T Ethernet Ports
Max video Storage Rate (Mbps)		360Mbps	600Mbps	600Mbps	600Mbps	600Mbps	600Mbps
Storage	Max Storage	48TB	112TB	96TB raw storage	320TB raw storage	192TB raw storage	192TB raw storage	288TB raw storage	416TB raw storage
Storage	RAID Options	---	---	RAID5	RAID5, 6	RAID5	RAID5	RAID5, RAID6 options
Local Video Output		True HD output or VGA or DVI	True HD output or VGA or DVI	True HD output or VGA or DVI	4x Mini display port to true HD adapters (included)	3 x mini DisplayPort (1 x mini-DP to true HD adapter included) Nvidia Quadro P400 GPU		3 x mini DisplayPort (1 x mini-DP to true HD adapter included) NVIDIA T400 2GB
Field Repair Kit		---	---	---	DW-FRK4U	---	---	---	---
Certifications		ONVIF, NDAA/TAA	ONVIF, NDAA/TAA	ONVIF, NDAA/TAA	ONVIF, NDAA/TAA	UL listed, ONVIF, NDAA/TAA	UL listed, ONVIF, NDAA/TAA	UL listed, ONVIF, NDAA/TAA	UL listed, ONVIF, NDAA/TAA
Warranty		5 year limited	5 year limited	5 year limited	5 year limited	5 year warranty, next business day on-site hardware service, keep your hard drive

Key Technologies

DW Spectrum^® IPVMS

Access and control from your phone or tablet: Our iPhone^® and Android^® app allow you to check in on your business from across town or across the country.
Learn More

Dual Power Supply

Redundacy for reliability.

* See product pages and specifications.

Hot Swappable Drives*

When a drive needs to be replaced, you can easily hot-swap it with a new one, while the system is still running. There is no need to power down and lose important minutes of data to maintain your system's drives healthy and operating.

Dual Network Cards

Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR's communication.

* See product pages and specifications.

RAID Storage Mirroring*

Add extra security to your video surveillance system by protecting recorded data and overcoming data loss in the case of a hard drive failure.

USB Mouse and Keyboard Included

Blackjack^® servers come with a USB mouse and
keyboard included at no extra cost.

Railkit Included

All Blackjack^® rackmount servers come with the rail kits included at no extra cost for easy out-of-the-box installation.

Next business day onsite hardware repair after remote diagnosis

If an issue occurs with your product that cannot be resolved by phone, DW will dispatch a certified technician to attempt repair of your machine at your place of business, usually the next business day.

* On supporting models. See product specifications.

Keep your drive after replacement to ensure data security

Our Keep Your Drive Warranty delivers users replacement hard drives, without the need to return the defective drives. Users can keep their drives and protect their data and their customer’s privacy.

Designed and comissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

NDAA / TAA Compliant

DW^® IP cameras, analog cameras, NVRs, DVRs, network devices and management software sold and distributed worldwide are designed and developed in U.S.A. and Korea. Manufacturing is done in Korea.

Most DW^® products qualify for GSA Schedule Contracts and other government opportunities because they are TAA / NDAA compliant.

Learn More
