Home Products 2U rackmount 12-bay server with 32GB dual Intel Xeon Silver processor

Share this Product!
2U rackmount 12-bay server with 32GB dual Intel Xeon Silver processor
Model: DW-BJRR2PxxT, DW-BJRR2PxxTLX, DW-BJRR2PxxTS
Find a Reseller | Request a Demo | Contact Us

This dual processor Blackjack® Rack™ server is the ultimate solution for recording multiple IP cameras of any resolution at up to 600Mbps throughput. The server is NDAA/TAA compliant, UL listed and includes Windows 10®, Windows Server® 2019 or Linux® Ubuntu® OS on a separate 240GB NVMe SSD. The 2U rack-mountable hardware features dual Intel® Xeon® processors, 32GB memory, dual network cards, dual power supply, mini DisplayPort outputs and removable hot-swappable drives. The Blackjack Rack server comes preloaded with DW Spectrum® IPVMS and eight recording licenses, up to 192TB raw internal storage with RAID5 and is ONVIF conformant The server comes complete with a 5-year, on-site, Next Business Day**, Keep Your Hard Drive warranty to ensure peace of mind.

** After remote diagnosis.

NDAA TAA


  • DW-BJRR2P

Max throughput and IP camera support
This Blackjack® server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 600Mbps throughput.
Next business day onsite hardware repair after remote diagnosis
If an issue occurs with your product that cannot be resolved by phone, DW will dispatch a certified technician to attempt repair of your machine at your place of business, usually the next business day.
Keep your drive after replacement to ensure data security
Our Keep Your Drive Warranty delivers users replacement hard drives, without the need to return the defective drives. Users can keep their drives and protect their data and their customer’s privacy.
DW Spectrum® IPVMS
DW Spectrum® IPVMS is an endlessly customizable IP Video Management platform that gives users the ability to create tailored network video solutions for any type of project, from the office or on in the field.
Designed and commissioned in the U.S.A
All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.
Dual network cards
Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR’s communication.
Dual power supply
Redundancy for reliability.
Hot-swappable HDDs
When a drive needs to be replaced, you can easily hot-swap it with a new one, while the system is still running. There is no need to power down and lose important minutes of data to maintain your system’s drives healthy and operating.
  • Supports ONVIF conformant IP cameras
  • Storage options 64-192TB raw internal storage with RAID5
  • Hot-Swappable HDDs
  • Redundant power supply
  • Dedicated GPU for client application for easy configuration
  • Intel® Xeon® processor
  • Dual network ports
  • Windows 10®, Ubuntu® Linux®, Windows Server® 2019 OS on NVMe SSD, RAID1
  • Hosting DW Spectrum® for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability and auto device discovery
  • Dual-stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL listed
  • NDAA/TAA compliant
  • 5 year warranty, next business day on-site hardware service*, keep your hard drive  - *after remote diagnosis
Included IP licenses
8
Form factor
2U Rackmount
Operating system
Windows® 10
DW-BJRR2PxxT
Linux Ubuntu® 18.04 LTS DW-BJRR2PxxTLX
Windows Server® 2019 DW-BJRR2PxxTS
OS on NVMe SSD
2 x 240GB NVMe SSD (RAID1)
CPU
Dual Intel® Xeon® Silver processor
Memory
32GB (4x 8GB)
Ethernet port
2 x 1Gigabit Ethernet (RJ45)
Option: DW-BJRR10GBN - Dell Broadcom 57412 Low Profile Dual Port 10Gb SFP+ NIC***
System
Maximum video storage rate (Mbps)
600 Mbps
Storage
Maximum HDD
12 x 3.5" SATA HDD
  Maximum storage Max raw 192TB, RAID5
Video-out
Outputs
3 x mini DisplayPort (1 x mini-DP to true HD adapter included)
Video card
Nvidia Quadro P400
Pre-loaded VMS software
DW Spectrum® IPVMS
Remote clients
Cross-platform - Windows®, Linux Ubuntu® and Mac®
Mobile apps
iOS® and Andriod®
DW Site Viewer
DW Spectrum App
Keyboard and mouse
Included
Rail kit
Included
Power supply
Dual 750W Redundant*
Operating temperature (ambient room temperature)
41°F~104°F (5°C~40°C)
Operating humidity
5~85% RH
Dimension (WxDxH)
19” x 28.25” x 3.41” (482.6 x 717.55 x 86.61mm)
Certification FCC and CE
Warranty
5 year warranty with next business day on-site  hardware repair**

* A UPS is recommended.
** After remote diagnosis.
*** Available at initial order.

Model #*

Usable Storage Size**

Open Drive Bays

DW-BJRR2P64T
46TB (RAID5)
8
DW-BJRR2P80T
64TB (RAID5)
7
DW-BJRR2P96T
80TB (RAID5)
6
DW-BJRR2P112T
96TB (RAID5)
5
DW-BJRR2P128T
112TB (RAID5)
4
DW-BJRR2P144T
128TB (RAID5)
3
DW-BJRR2P160T
144TB (RAID5)
 2
DW-BJRR2P176T
160TB (RAID5)
 1
DW-BJRR2P192T
176TB (RAID5)
 ---
* For Linux OS models, add LX at the end of the part number.
* For Windows Server OS models, add S at the end of the part number.

** RAID5 configuration reduces raw storage size by the equivalent of one (1) HDD size.
DW Spectrum IPVMS Licensing Options

Part Number

Description

DW-SPECTRUMLSC001
Single DW Spectrum IPVMS License, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS004
Four (4) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS010
Ten (10) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS020
Twenty (20) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS050
Fifty (50) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS100
One Hundred (100) W Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC004
Single DW Spectrum IPVMS License - allows up to 4-channel or recording when used with DW-CP04 and DW-CP16, No Annual Renewal, No Upgrade Required.
DW-SPVWALL1X2Single DW Spectrum IPVMS Video Wall license - 1 Operator, 2 Monitors, No Annual Renewal, No Upgrade Required.

Additional Hardware Options (Available at time of initial order only):

Part Number

Description

DW-BJRR32GB
32GB Ram Upgrade for Blackjack RACK.
DW-BJRR4NICLow Profile Quad Port 1GbE RJ45 for Blackjack RACK.
DW-BJRR10GBNLow Profile Dual Port 10Gb SFP+ NIC for Blackjack RACK.
