IMAGE |
||
Image sensor |
5MP 1/2.8” CMOS |
|
Total pixels |
2592 (H) × 1944 (V) |
|
Minimum scene illumination |
0.08 lux (color) |
|
0.0 lux (B/W) |
||
Test Monitor Video Output |
Local video output CVBS 1.0V p-p (75?), 4:3 aspect ratio |
|
LENS |
||
Focal length |
2.7 ~ 13.5mm, F1.4 | |
Lens type |
Vari-focal p-iris lens with motorized-zoom and auto-focus | |
Field of view (FoV) |
31° ~ 96° |
|
IR distance |
100ft range |
|
Optical zoom |
x5 optical zoom |
|
I/O |
||
Audio in / out |
1 input / 1 output |
|
Audio compression |
G.711 |
|
Alarm in / out |
1 input / 1 output |
|
OPERATIONAL |
||
Intelligent Video Analytics |
IVA license: intrusion, line crossing, counting line, loitering, enter, exit, tamper |
|
IVA+ license: object removed, tailgating, direction, stopped, appear, disappear, object left |
||
Shutter mode |
Auto, manual, anti-flicker, slow shutter |
|
Shutter speed |
1/15 ~ 1/32,000 |
|
| Slow shutter | 1/2,1/3,1/5,1/6,1/7.5, 1/10 | |
Auto gain control |
Auto |
|
Day / night |
Auto, day (color), night (B/W) |
|
Smart DNR™ 3D digital noise reduction |
3D DNR |
|
Wide dynamic range (WDR) |
True WDR (T-WDR) |
|
| Wide dynamic range (WDR) dB | 120dB | |
| Privacy zones | 16 programmable privacy masks | |
| Mirror and flip | Yes | |
Alarm notifications |
Notifications via e-mail, FTP, alarm output activation and SD card recording |
|
Memory slot |
Micro SD / SDHC / SDXC (card not included) |
|
NETWORK |
||
LAN |
RJ45 (10/100Base-T) |
|
Video compression type |
H.265, H.264, MJPEG |
|
Resolution |
H.265: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF |
|
Frame rate |
Up to 30fps at all resolutions |
|
Video bitrate |
100Kbps ~ 10Mbps, Multi-rate for Preview and Recording |
|
Bitrate control |
Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth) |
|
Streaming capability |
Dual-stream at different rates and resolutions |
|
IP |
IPv4, IPv6 |
|
Protocol |
TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF |
|
Security |
HTTPS(TLS), IP filtering, 802.1x, digest authentication (ID/PW) |
|
ONVIF conformance |
Yes |
|
Web viewer |
OS: Windows®, Mac® OS, Linux® Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari® |
|
Video management software |
DW Spectrum® IPVMS |
|
ENVIRONMENTAL |
||
Operating temperature |
-40°F ~ 122°F (-40°C ~ 50°C)
|
|
Operating humidity |
10–90% RH (non–condensing)
|
|
IP rating |
IP68-rated
|
|
| IK rating | IK10 impact-resistant | |
Other certifications |
CE, FCC, RoHS
 |
|
ELECTRICAL |
||
Power requirement |
DC12V, POE IEEE 802.3af class 3 (adaptor not Included)
|
|
Power consumption |
DC12V: max 8.3W PoE: max 10.5W
|
|
MECHANICAL |
||
Material |
Snapit™ aluminum vandal housing, polycarbonate dome
|
|
Dimensions |
5.47" x 4.93" (139 x 125.4mm) |
|
Weight |
2.75 lbs (1.25kg) |
|
| Warranty | 5 year warranty | |
