IMAGE |
||
Image sensor |
5MP 1/2.8” CMOS |
|
Total pixels |
2592 (H) × 1944 (V) |
|
Minimum scene illumination |
0.13 lux (color) |
|
0.0 lux (B/W) | ||
LENS |
||
Focal length |
2.8mm, F1.8 | |
Lens type |
Fixed lens | |
Field of view (FoV) |
103° |
|
IR distance |
100ft range | |
OPERATIONAL |
||
Intelligent Video Analytics |
IVA license: intrusion, line crossing, counting line, loitering, enter, exit, tamper |
|
IVA+ license: object removed, tailgating, direction, stopped, appear, disappear, object left |
||
Shutter mode |
Auto, manual, anti-flicker, slow shutter |
|
Shutter speed |
1/15 ~ 1/32,000 |
|
| Slow shutter | 1/2,1/3,1/5,1/6,1/7.5, 1/10 | |
Auto gain control |
Auto |
|
Day / night |
Auto, day (color), night (B/W) |
|
Smart DNR™ 3D digital noise reduction |
3D DNR |
|
Wide dynamic range (WDR) |
True WDR (D-WDR) On, Off |
|
| Wide dynamic range (WDR) dB | 120dB | |
| Privacy zones | 16 programmable privacy masks | |
| Mirror and flip | Yes | |
Alarm notifications |
Notifications via e-mail, FTP and alarm output | |
NETWORK |
||
LAN |
RJ45 (10/100Base-T) |
|
Video compression type |
H.265, H.264, MJPEG |
|
Resolution |
H.265: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF |
|
Frame rate |
Up to 30fps at all resolutions |
|
Video bitrate |
H.264 / H.265: 32Kbps ~ 14Mbps MJPEG: 1Mbps ~ 40Mbps |
|
Bitrate control |
H.265 dual-stream or simultaneous H.265 / H.264 / MJPEG |
|
Streaming capability |
Dual-stream at different rates and resolutions |
|
IP |
IPv4, IPv6 |
|
Protocol |
TCP/IP, UDP, AutoIP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB-2), ONVIF |
|
Security |
HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW) |
|
ONVIF conformance |
Yes |
|
Web viewer |
OS: Windows®, Mac® OS, Linux® Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari® |
|
Video management software |
DW Spectrum® IPVMS |
|
ENVIRONMENTAL |
||
Operating temperature |
-4°F ~ 122°F (-20°C ~ 50°C)
|
|
Operating humidity |
10–90% RH (non–condensing)
|
|
| IK rating | IK10 impact resistant | |
IP rating |
IP67-rated
|
|
Other certifications |
CE, FCC, RoHS
 |
|
ELECTRICAL |
||
Power requirement |
DC12V, POE IEEE 802.3af class 3 (adaptor not Included)
|
|
Power consumption |
DC12V: max 6.5W PoE: max 7.8W
|
|
MECHANICAL |
||
Material |
Aluminum vandal ball housing
|
|
Dimensions |
4.92" x 4.8" (125 x 122 mm) |
|
Weight |
1.76 lbs (0.8kg) |
|
| Warranty | 5 year warranty | |
