Home Products MEGApix® 4MP bullet camera with 6~50mm vari-focal p-iris lens with motorized zoom and auto-focus and IR

Share this Product!
Bullet camera with 6~50mm vari-focal p-iris lens with motorized zoom and auto-focus and IR
Model: DWC-MB44Wi650
Find a Reseller | Request a Demo | Contact Us
DISCONTINUED

These MEGApix® IP cameras deliver crystal-clear images at 4 Megapixel resolution at real-time 30fps. Features include 6-50mm Long Range P-Iris Lens, Smart IR™, Smart DNR™ and WDR for quality video in challenging lighting environments. The IP66 rated weather-resistant housing is easy to install and will Cold Start at -40º F/-40º C.

NDAA
  • DWC-MB44Wi650

True Wide Dynamic Range (WDR)
Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.
Cold Start -40°F (-40°C)
The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.
  • 4MP 1/3” CMOS Sensor at Real-Time 30fps
  • 6~50mm Motorized Zoom Auto-Focus P-Iris Lens
  • True Wide Dynamic Range (WDR)
  • Dual Codecs (H.264, MJPEG) with Simultaneous Dual-Stream
  • Cold Start -40°F (-40°C)
  • 140’ Smart IR™ with Intelligent Camera Sync.
  • Smart DNR™ 3D Digital Noise Reduction
  • True Day/Night with Mechanical IR Cut Filter
  • Programmable Privacy Zones
  • Auto Gain Control (AGC)
  • Auto White Balance (AWB)
  • Motion Detection
  • Two-Way Audio
  • Micro SD/SDHC/SDXC Class 10 Card Slot (Card Not Included)
  • Alarm Sensor Input
  • Relay Output
  • Web Server Built-in
  • PoE Class 3 and DC12V
  • UL listed
  • OnVIF Conformant, Profile S
  • NDAA compliant
  • IP66 Weather and Tamper Resistant
  • 5 Year Warranty

Image sensor
4MP 1/3” CMOS
Total pixels
2688 (H) x 1520 (V)
Minimum scene illumination
0.26 lux (color)
0.0 lux (B&W)
Test Monitor Video Output
Local video output CVBS 1.0V p-p (75 ?), 4:3 aspect ratio

LENS
Focal length
6-50mm, F1.6
Lens type
Motorized-zoom auto-focus p-iris lens
Field of view (FoV)
40.8° ~ 6.9°
IR distance
140ft range
Optical zoom
x8.3

I/O
Audio in / out
1 input / 1 output
Audio compression
G.711
Alarm in / out
1 input / 1 output

OPERATIONAL
Shutter mode
Auto, manual, anti-flicker, slow shutter
Shutter speed
1/15~1/32000
Slow shutter
off, x2, x3, x5, x6, x7.5, x10
Auto gain control
Auto
Day / night
Auto, day (color), night (B/W)
Smart DNR™ 3D digital noise reduction
0~11
Wide dynamic range (WDR)
True WDR off, WDR2x, WDR3x
Wide dynamic range (WDR) dB
120dB
Privacy zone
16 programmable privacy masks
Alarm notifications
Notifications via e-mail, FTP server, alarm output activation or SD card recording
Memory slot
Micro SD / SDHC / SDXC (card not included)

NETWORK
LAN
802.3 compliance 10/100 LAN
Video compression type
H.264, MJPEG
Resolution
H.264: 1440p/1080p/720p/VGA/D1/CIF MJPEG: 1280x720/800x600/VGA/768x432/D1/CIF
Frame rate
Up to 30fps at all resolutions
Video bitrate
100Kbps ~ 10Mbps, multi-rate for preview and recording
Bitrate control
Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
Streaming capability
Dual-stream at different rates and resolutions
IP
IPv4
Protocol
Zero config(Auto IP), ONVIF, TCP/IP, UDP, RTP(UDP/TCP), RTSP, NTP, HTTP,HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2c/v3(MIB-2)
Security
HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW)
ONVIF conformance
Yes
Web viewer
OS: Windows®, Mac® OS, Linux® Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari®
Video management software
DW Spectrum® IPVMS

ENVIRONMENTAL
Operating temperature
-40°F ~ 122°F (-40°C ~ 50°C)
Operating humidity
10–90% RH (non–condensing)
IP rating
IP66 certified weather and tamper-resistant
Other certifications
CE, FCC, RoHS

ELECTRICAL
Power requirement
DC12V, POE IEEE 802.3af class 3 (adaptor not Included)
Power consumption
DC12V: Max 11W PoE: Max 12.9W

MECHANICAL
Material
Aluminum bullet housing
Dimensions
9.73” x 3.8” (247.2 x 96.7mm) *Dimensions based on the position of the sun shield cover
Weight
1.98 lbs (0.9kg)
DWC-BLJUNC
Junction box for bullet cameras
DWC-PMB-WLW
Pole mount bracket for bullets and dome cameras
Title Type Size Download
Camera part numbering system pdf 0.03 MB
DW Accessories Chart xlsx 0.05 MB
DWC-MB44Wi650 AE specifications doc 0.09 MB
DWC-MB44Wi650 datasheet pdf 0.49 MB
DWC-MB44Wi650 datasheet - Spanish pdf 0.40 MB
DWC-MB44Wi650 quick setup guide pdf 1.84 MB
DWC-MB44Wi650 UL certificate pdf 0.34 MB
DWC-MB44Wi650 user manual pdf 5.61 MB
MEGApix Single-Sensor Brochure pdf 3.29 MB
DWC-MB44Wi650 CAD Drawing dwg 0.32 MB
Title Type Release Notes Version Compatibility Size Download
DW IP Finder v4.4.14 for Linux OS run - v4.4.14 47.86 MB
DW IP Finder v4.4.14 for Windows OS exe - v4.4.14 17.64 MB
MEGApix 4MP Firmware vA2.1.2-20180619 img - vA2.1.2-20180619 MEGApix 4MP IP cameras 0.00 MB
