IMAGE | ||
Image sensor | 1/2.7“ 2.1M CMOS | |
Total pixels | 1930 x 1088 | |
Minimum scene illumination | 1.4 lux (Color) 0.00 lux (B/W) | |
LENS | ||
Focal length | DWC-MV72i28V: 2.8mm Lens, F2.0 (Discontinued) DWC-MV72i4V: 4.0mm Lens, F2.0 | |
Lens type | Fixed Lens | |
IR distance | 50ft Smart IR™ | |
Angle of view | DWC-MV72i28V: 109° (Discontinued) DWC-MV72i4V: 82° | |
OPERATIONAL | ||
Shutter mode | Auto | |
Shutter speed | 1/30(25)sec ~ 1/10,000sec | |
White balance | Auto indoor / auto outdoor / push / manual / hold | |
Auto gain control | Max 64dB | |
Day and night | Auto, day (color), night (B/W), schedule | |
NETWORK | ||
LAN | 802.3 compliance 10/100 base T LAN | |
Video compression type | H.264, MJPEG | |
Resolution | 1080p / D1 / VGA / CIF / QVGA | |
Frame rate | 1-30fps | |
Streaming capability | Multistreaming CBR/VBR (controllable frame rate and bandwidth) | |
IP | IPv4, IPv6 | |
Protocol | ONVIF, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, DNS, DDNS, DHCP | |
Maximum user access | 4 users | |
ONVIF conformance | ONVIF Profile S | |
Web viewer | Browser: Internet Explorer®, Google Chrome®, Firefox® OS: Windows® 7 | |
ENVIRONMENTAL | ||
Operating temperature | -4°F ~ 122°F (-20°C ~ 50°C) | |
Operating humidity | Less than 90% (Non-Condensing) | |
| IK rating | IK10 impact resistant | |
IP rating | IP67-rated | |
Other certifications | FCC, CE, ROHS | |
ELECTRICAL | ||
Power requirements | DC 12V, POE IEEE 802.3af class 2 | |
Power consumption | LED off: 1.9W, 155mA LED on: 3W, 250mA | |
MECHANICAL | ||
Material | Aluminum die-casting | |
Dimensions | 4.13" x 2.38" (105 x 60.7mm) | |
Weight | 0.95 lbs (0.35 kg) |
